| Material |
| Rack : Metal |
| Fan : Plastic |
| Characteristic |
| Version : DC fan 12V 2A, compact and powerful, noise and efficiency optimized delta blower fan |
| Direction of air flow : exhaust over struts |
| Direction of rotation : counter clock wise, looking towards rotor |
| Installation : 1U 19” standard server rack |
| Bearing : ball bearings |
| Operating mode : Continuous operation (s1) |
| IP protection class : IP20 Switch : adjustable controller |
| Electrical hookup : via single wires AWG22 |
| Electrical protection class : III |
| Weight : 1.8kg |
| Approvals |
| DIN EN62368, UL507, CSA C22, Nr.113, EAC, CE, UKCA, CCC (only necessory >36V) |
| Controller |
| Speed : from 0 to 4500rpm |
| Output voltage : 12v 2A |
| Options |
| External temperature sensor |
| PWM control input |
